Spection
Description | OD mm(in) | ID mm(in) | OAL mm(in) | Conn. |
3-1/2” Pin tool joint | 127(5) | 66(2-19/32) | 370(14-9/16) | NC38 |
3-1/2” Box tool joint | 127(5) | 66(2-19/32) | 370(14-9/16) | NC38 |
5”Pin tool joint | 165.1(6-1/2) | 82.6(3-1/4) | 388(15-9/32) | NC50 |
5”Box tool joint | 165.1(6-1/2) | 90.5(3-9/16) | 360(14-11/64) | NC50 |
5”Pin tool joint | 168.3(6-5/8) | 82.6(3-1/4) | 395(15-35/64) | NC50 |
5”Box tool joint | 168.3(6-5/8) | 88.9(3-1/2) | 374(14-47/64) | NC50 |
5-1/2” Pin tool joint | 184.2(7-1/4) | 87.3(3-7/16) | 484(19-3/64) | 5-1/2 FH |
5-1/2” Box tool joint | 184.2(7-1/4) | 87.3(3-7/16) | 459918-5/64) | 5-1/2 FH |
